Kayak HD — Installation and Service Manual 177
Appendix
C
Field Replaceable Units and
RoHS Compliance
This appendix provides lists of the Field Replaceable Units (FRU) for the
Kayak Video Production Center along with their standard and RoHS
(Restriction of the use of certain Hazardous Substances) compliant part
numbers.
Note The lists given here are for general guidelines only and are subject to change
at any time. They do not reflect current pricing or availability information.
The modules and assemblies in the Kayak Video Processor frame and
Control Panel surfaces that can be replaced in the field and ordered from
Grass Valley Customer Service are listed in
Table 21 .
Table 21. Kayak HD FRU List and RoHS Compliant Part Numbers
Non-RoHS RoHS RoHS 5 of 6
Hardware
Kayak HD Large Backplane (8 RU) 6716715XX 7510150XX
Kayak HD Backplane (4 RU) 6716629XX 7710059XX
Kayak HD Frame Power Supply 6200096XX
Kayak HD Control Proc without RAM Recorder 6716630XX
Kayak HD Control Proc with RAM Recorder N/A 7710060XX 6910000XX
Kayak HD Mix/Effects 6716631XX 7710061XX
Kayak HD Transition 6716632XX 7710062XX
Kayak HD Fan (8 RU) N/A 7510149XX
Kayak HD Fan (4 RU) N/A 7510063XX
Panels
Kayak HD 1 M/E Panel 6600049XX
Kayak HD 2 M/E Panel 6600055XX
Kayak HD 3 M/E Panel 6600067XX
Frames
Kayak HD 4 RU Frame 6600058XX
Kayak HD 8RU Frame 6600068XX
Software
Kayak Software CD (includes documentation) 0638147XX
