172 Kayak HD — Installation and Service Manual
Appendix B — Control Interfaces
Note Every M/E related command affects the DD35/XtenDD/Kayak PP M/E stage by
default. To affect another M/E use the Editor M/E Mapping feature. The GVG
DSK command is always translated to Key3 in the PP “mapped” M/E stage.
Note Standard GVG200 protocol timing is used. Commands are executed in the
third field after response. If there are timing problems, fix them by changing
the timing parameters of the editor.
TRANSITION RATE COMMAND CC/CD/FD Only Write
LEARN E-MEM REGISTER DA
RECALL E-MEM REGISTER DB
ALL STOP COMMAND F2
TRANSITION PUSHBUTTON SELECT
COMMAND
FB
Supported are:
Program Bus Crosspoint 0-9 / 00H - 09H
AUTO TANS / 0BH
DSK MIX / 0CH
DSK CUT / 0DH
WIPE / 0EH
MIX / 0FH
Preset Bus Crosspoint 0-9 / 10H -19H
REVERSE WIPE / 1DH
FADE TO BLACK / 1FH
Key Bus Crosspoint 0-9 / 20H -29H
GVG100 Wipe Pattern / 30H -39H
BKGD / 48H
KEY / 49H
CUT / 4AH
KEY CUT / 52H
Name Command Code Remark
