Kayak HD — Installation and Service Manual 169
Table 16. Serial Digital Video Inputs
Table 17. Serial Digital Video Outputs
Format
ITU-R656, SMPTE 259M, 270Mbit/s.
SMPTE 292M, 1.5Gbit/s
Number of Inputs
Kayak HD 100C, 150C: 24 to 48
Kayak HD 200C, 250C: 48
Kayak HD 200, 250: 48 to 96
Kayak HD 300: 72 to 96
Return loss > 15 db, 5 MHz to 1.5 GHz
Type of Connector 75 ohm BNC (SMPTE 259M)
Interface
HD Video Formats SMPTE 292M-1998
SD Video Formats SMPTE 259M-1997
Nominal Amplitude 800mV peak-to-peak terminated
Autophasing range TBD
Channel Coding conforms to SMPTE 259M, SMPTE 292M
Ancillary Data Blanked or passed (user selectable).
NOTE: Video passing through Scalars or iDPMS will be blanked of any
ancillary data or embedded audio.
Embedded audio
EDH Blanked
Input Impedance 75 ohm
Max cable length
HD Video 100 meters using Belden 1694A type cable
SD Video 300 meters using Belden 1694A type cable
Format
ITU-R656, SMPTE 259M, 270Mbit/s.
SMPTE 292M, 1.5Gbit/s
Number of Outputs
Kayak HD 100C, 150C: 12 min., Up to 24
Kayak HD 200C, 250C: 24
Kayak HD 200, 250: 24 min., Up to 48
Kayak HD 300: 36 min., Up to 48
Return loss > 15 db, 5 MHz to 1.5 GHz
Type of Connector 75 ohm BNC (SMPTE 259M)
Interface
HD Video Formats SMPTE 292M-1998
SD Video Formats SMPTE 259M-1997
Nominal Amplitude 800 mv peak-to-peak across 75 ohm
Rise & Fall Times
400 to 1400picoseconds 75 ohm termination
between 20% and 80% amplitude
Jitter ITU R 601/656
Output Impedance 75 ohm
DC Offset < 50mV with 75 ohm termination
