Machine Torch SeTup
powermax
105 Service Manual 6-19
105 A Shielded cutting (Stainless Steel) Air flow rate – slpm/scfh
Hot 217 / 460
Cold 250 / 530
Metric
Material
thickness
torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay time
best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
6
3.2
6.4 200
0.5
4870 139 6000 141
8 3460 141 4210 142
10 2240 144 2670 142
12 0.6 1490 148 1860 144
16 0.75 950 149 1080 149
20 8.0 250 1.25 660 154 810 152
25
Edge Start
440 158 530 156
30 340 164 360 160
32 300 166 320 163
English
Material
thickness
torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay time
best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm Volts ipm Volts
1/4
0.125
0.25 200
0.5
185 139 224 141
3/8 94 143 112 142
1/2 55 148 68 145
5/8 0.75 38 149 43 149
3/4 0.31 250 1.25 28 153 34 151
7/8
Edge Start
22 156 27 153
1 17 158 20 156
1-1/8 14 162 16 159
1-1/4 12 166 13 163
