Machine Torch SeTup
powermax
105 Service Manual 6-41
105 A Unshielded cutting (Aluminum) Air flow rate – slpm/scfh
Hot 217 / 460
Cold 250 / 530
Metric
Material
thickness
torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay time
best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
6
4.6
9.2 200
0.5 5840 148 7170 149
8
0.75
4110 152 5060 151
10 2670 154 3580 153
12
1.0
2090 155 2450 154
16 1330 160 1660 158
20
Edge Start
980 163 1190 162
25 660 167 770 167
30 500 170 590 169
32 450 171 520 170
English
Material
thickness
torch-
to-Work
Distance
Initial Pierce Height
Pierce
Delay time
best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm Volts ipm Volts
1/4
0.180
0.36 200
0.5 218 149 268 149
3/8 0.75 110 154 136 153
1/2
1.0
77 156 91 155
5/8 51 160 66 158
3/4 1.25 41 162 50 161
7/8
Edge Start
33 165 40 164
1 25 167 29 167
1-1/8 20 169 25 169
