SMS-7000 Modem Protection Switch Operation
Rev. 3 3–11
3.4.2 Configuration Independent Prime 1 through 8 Menu
Refer to Figure 3-4.
PRIME MODEM #n
ADDRESS Set # other than 0. Address 0 is a global address which is used to
communicate with all modems even though the address is set to
something else.
Address: 0 to 255
Upon entry, the current status is displayed. Press [
↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME MOD #n Must be On for the switch to recognize it as active.
Upon entry, the current status is displayed. Press [
↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME MOD #n
PRIORITY Options: LOW, MEDIUM, and HIGH.
Upon entry, the current status is displayed. Press [ ↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME MOD #n DELAY NONE
MANUAL = 0.5 to 127.0 SEC.
Upon entry, the current status is displayed. Press [
↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME DEMOD #n Must be On for the switch to recognize it as active.
Upon entry, the current status is displayed. Press [
↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME DEMOD #n
PRIORITY Options: LOW, MEDIUM, and HIGH.
Upon entry, the current status is displayed, Press [
↑] or [ ↓] to make
the selection. Press [ENTER} to execute the change.
PRIME DEMOD #n
DELAY NONE
AUTO
MANUAL = 0.5 to 127.0 SEC.
Upon entry, the current status is displayed. Press [ ↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME #n
MULTIPLEXER Displayed if multiplexer is; ‘YES or NO.’
Upon entry, the current status is displayed. Press [ ↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
PRIME DEMOD #n
MULTIPLEXER
ADDRESS
(Menu applies, only if
multiplexer is attached.)
Set # other than 0. Address 0 removes the multiplexer from the
system.
Address: 0 to 255
Upon entry, the current status is displayed. Press [
↑] or [ ↓] to make
the selection. Press [ENTER] to execute the change.
