Users Manual – 610 / 611/ 612 Printers 3. Setting Supply Options • 27
Dispense Position
This function adjusts the stopping point of the label.
To change the setting, from the Main Menu, select Setup, Supply, then Positioning. Follow
these steps.
1. Press Í or Î until you see
POSITIONING
Å
Dispense Pos Æ
2. Press Enter/Pause.
DISPENSE POS
[50/200]: +65
3. Press Í or Î to change the dispense position. Pressing Í decreases the value; Î
increases it.
4. Press Enter / Pause when the number you need appears. Press Escape / Clear until
you see the Main Menu.
Backfeed Distance
This is the amount to move the label backwards. The backfeed distance can not be greater
than the dispense position. If you make the backfeed distance greater than the dispense
position, the dispense position automatically changes to match the backfeed distance.
The backfeed distance should equal the dispense position. An exception is when you are
tearing labels, instead of peeling. Then, the backfeed distance must be 30 dots (0.15 inches)
less than the dispense position to account for improper tearing of butt cut supplies. You will
have a 30-dot non-print zone on your supply, but this prevents exposed adhesive under the
printhead.
To change the setting, from the Main Menu, select Setup, Supply, then Positioning. Follow
these steps.
1. Press Í or Î until you see
POSITIONING
Å
Backfeed Dis
2. Press Enter/Pause.
BACKFEED DIS
[10/200]: +65
3. Press Í or Î to change the dispense position. Pressing Í decreases the value; Î
increases it.
4. Press Enter / Pause when the number you need appears. Press Escape / Clear until
you see the Main Menu.
