Asymmetric Test
10 Gigabit Ethernet Analyzer 47
Testing Example
2. Connect the local and remote device according to the scheme shown
in the scheme image on this page.
3. On the local and remote device switch to the ETS-1000G. Setup >
Network Setup menu and set:
Interface – Test
One of the following methods specify the IP address of local device (IP
1) and remote device (IP 2):

set IP address manually;

receive IP address via DHCP.
4. On the local device switch to the BERT > Setup > Topology menu.
Set:
Remote IP – IP 2
Direction – Upstream
