EXFO ETS-1000G - Manual (Page 172)

Remote Control Commands
162 ETS-1000G
Remote control commands (TELNET). Configuration mode
Remote control commands (TELNET).
Configuration mode
Command Action
RFC 2544
rfc2544 header src udp int Set the source UDP port number.
rfc2544 header src mac
XX:XX:XX:XX:XX:XX
Set the source MAC address.
rfc2544 header src ip i.i.i.i Set the source IP address.
rfc2544 header dst udp int Set the destination UDP port number.
rfc2544 header dst mac
XX:XX:XX:XX:XX:XX
Set the destination MAC address.
rfc2544 header dst ip i.i.i.i Set the destination IP address.
rfc2544 header vlan count off/1/2/3 Select the number of VLAN tags.
rfc2544 header vlan [1-3] id int Set the VLAN identifier value.
rfc2544 header vlan [1-3] priority int Set the traffic priority value.
rfc2544 header mpls count o/1/2/3 Select the number of labels.
rfc2544 header mpls [1-3] label long Set the label value.
rfc2544 header mpls [1-3] cos int Set the Class of Service of a packet.
rfc2544 header mpls [1-3] ttl int Set the time-to-live of a labeled packet.
rfc2544 header autoarp off/on Disable/enable the feature of submitting an
ARP request automatically.
rfc2544 header diffserv prec+tos / dscp Select the IP Precedence field and the Type of
Service field or the DSCP field for inserting.
rfc2544 header dscp text Set the value of the DSCP field, 8 bits.
rfc2544 header precedence int Set the frame priority value.
