EXFO ETS-1000G - Manual (Page 150)

Specifications
140 ETS-1000G
Testing
Delay Variation Test results: PKTs, OOOPs, INOPs, %OOOPs, %INOPs,number of
packets, for which the jitter/latency was below (above) the
specified threshold. Support for the modes of random and fixed
frame sizes.
Complex traffic Up to 10 data streams with individual load and frame headers.
Frame loss for each data stream; the bandwidth calculated
according to the results of testing. The current, minimum,
average and maximum data deference values. The number of
sent and received packets for each data stream.
Statistics (RFC 2819) Statistics of frame types, frame sizes, layers, error frames. The
number of received and transmitted packets, displaying the port
load in the real time. Frame types: broadcast, multicast, unicast.
Runt packets, jabber packets. The number of frames transmitted
on the data link and network layers. CRC, checking for runt,
jabber.
DNS Determining an IP address of a network device according to the
known domain name.
Route Determining data transmission routes in the TCP/IP networks.
Ping The minimum, average, maximum time periods between
sending a request and receiving a reply. The number of sent,
received, lost and repeated packets. The number of packets for
which the response time has been exceeded.
ARP request monitor The possibility to monitor the ARP responses being transmitted
in the network and intercept the device IP and MAC addresses
which are contained in them.
TCP client Establishing a TCP connection to a remote network device,
controlling over TELNET, sending a HTTP GET request.
Loopback Layers: the physical layer, the data link layer with support for
VLAN, the network layer, the transport layer.
ET discovery Enabling the Loopback mode on a remote analyzer (ETS-1000G)
or a remote loopback device.
