Device Description
10 Gigabit Ethernet Analyzer
15
Control Menu Structure
The digit 1 in the above figure specifies the reset button.
Control Menu Structure
The main menu of the ETS-1000G device consists of three submenus
(hereinafter referred to as menus). To switch between them, use the
following keys:
(ETS-1000G Setup), (ETS-1000G
Tools),
(ETS-1000G Tests).
1. ETS-1000G Setup.
Marking
Description
10G
Connecting the SFP+ module
1G
RJ-45 connectors to connect to the tested network or
equipment (supported rates 10/100/1000 Mbps)
Port of the device contains 2 connectors — RJ-45 and SFP.
During the test only one connector of the port is used.
SFP-module connectors
LAN
Remote control of the tester
USB
Connecting to a PC via the USB interface
DC IN
External power unit connector
1
