Traffic Generator
10 Gigabit Ethernet Analyzer 93
Static Traffic
 Disable the test traffic generator.
 Specify the required threshold value.
 Specify measurement duration.
4. Open the Traffic generator menu on the local device and enable the
test traffic generation feature.
5. Open the Delay Variation > Summary menu on the remote device and press
(Start).
If the local and remote devices are connected to the network
according to the diagram to conduct the test, do the following:
1. Open the Network Setup menu on the local and remote devices,
specify the IP address of test port or make sure that the device has
received the correct IP address via DHCP.
2. Open the Traffic generator menu on the local device:

Set the generation parameters.

Set the header parameters according to the information provided
in Main header parameters on page 26 and Additional header
parameters on page 27 section.
3. Open the Delay Variation > Setup menu on the remote device:

Disable the test traffic generator.

Specify the required threshold value.

Specify measurement duration.
4. Open the Traffic generator menu on the local device and enable the
test traffic generation feature.
5. Open the Delay Variation > Summary menu on the remote device and
press (Start).
