Model MAV7057
3 POSITION - OPTION SWITCH
FUNCTION
CLOSED CIRCUITS
EXTRA RINSE
BU**-RD**
SOAK ONLY
(OPEN)
CANCEL
BK*-BK*
*1/4 Terminal - **3/16" Terminal
Model MAV8057
4 POSITION - OPTION SWITCH
FUNCTION
CLOSED CIRCUITS
SECOND RINSE
PU**-GY**
GENTLE SPIN
OR*-PK*
SOAK ONLY
(OPEN)
CANCEL
BR*-PU*, BK*-PK*,
RD**-GY**
*1/4" Terminal - **3/16" Terminal
Model MAV8000
4
POSITION - OPTION SWITCH
FUNCTION
CLOSED CIRCUITS
EXTRA RINSE
PU**-GY**
NORMAL RINSE
RD**-GY**
GENTLE SPIN
OR*-PK*
NORMAL SPIN
BK*-PK*
*1/4" Terminal - **3/16" Terminal
Model MAV8500
4 POSITION - OPTION SWITCH
FUNCTION
CLOSED CIRCUITS
EXTRA RINSE
PU*-BR*
REMINDER CHIME
RD**-GY**
CLEAN LIGHT
OR*-PK*
CANCEL
BK*-PK*
* 1/4" Terminal
**3/16" Terminal
Models MAV7057/8000/8057
4 POSITION - OPTION SWITCH
FUNCTION
CLOSED CIRCUITS
SUPERWASH
BK*-RD*, BK*-BU*
GENTLEWASH
OR*-BU*, RD*-OR*
TEMP CONTROL
(OPEN)
CANCEL
BR**-RD**,
BK*-BU*. OR*-RD*
WATER TEMPERATURE
The wash and rinse water temperatures can
be selected via the water temperature switch
on the control console for some models. On
upper end models, the water temperature is
controlled by a temperature control board, lo
cated on the back of the timer. (See section
discussing Temperature Contrai Board on
page 8-4 thru 8-5.)
16009485-01
Section 8. Electrical Components & Testing
©1999 Maytag Appliances Sales Company
8-18
