When the tub is empty, ohmmeter leads
placed across terminals 7 & 15 should in­
dicate continuity.
When the tub is filled as per the switch
setting and corresponding water depth (re­
fer to Specifications Section under Water
Level), terminals 7 & 15 should be open and
terminals 7 and 16 should indicate conti­
nuity.
Model MAV4500/5000
2 POSITION - OPTION SWITCH
FUNCTION CLOSED CIRCUITS
SUPERWASH BK-RD
NORMAL OR-RD
Fill Level Terminals Status
Empty 7& 15
7& 16
Closed
Open
Full 7& 15
7& 16
Open
Closed
SELECTOR SWITCHES
Model MAV5057
3 POSITION - OPTION SWITCH
FUNCTION CLOSED CIRCUITS
SUPERWASH BK*-RD*
EXTRA RINSE BU**-RD**
CANCEL OR*-RD*
*1/4" Terminal - **3/16" Terminal
Selector switch charts indicating the contact
alignment for the various positions of each
switch used appear on the schematic diagram.
These charts should be referred to for specific
information on the model being serviced.
Testing Selector Switches
The selector switch can be accessed as previ­
ously detailed in Section 4 under Control
Pane! Disassembly. It can be tested using an
ohmmeter and executing the following:
• Remove all switch wiring and perform
continuity checks using the respective se­
lector switch chart to indicate the proper
continuity.
Model MAV6000/6057/7000
4 POSITION - OPTION SWITCH
FUNCTION CLOSED CIRCUITS
SUPERWASH BK*-RD*
EXTRA RINSE BU^^-RD*""
AUTO. TEMR (OPEN)
CANCEL
BR**-RD**,
OR*-RD*
*1/4“ Terminals - **3/16" Terminals
OPTION SWITCH
The option switches allow the user to select
various options regarding Superwash, spin
speeds and end of cycle signal.
