Lower Bearing

And Housing —
Assembly

Oil Seal'

Transmission

' Housing

Assembly

Suspension
Housing

Retaining

Ring

Drive Tube
Splines

Brake Spring
Retainer

Brake Rotor

And Lining
Assembly

Brake

Stator

Spacer

Thrust Bearing

Washer (Curved)

Outer Edge

Turned Up

Washer (thin)

~ Upper Race

O) t Washer (thick)

Lower Race

Washer (thin)
Thrust

j Drive Pulley
I Assembly

Lower Cam ■

Retaining

Ring

-Thrust

Washer

■ Dust Cap

Figure 7-4

16009485-01

Section 7. Transmission And Related Components

7-5
