Potter PFC-4410RC User Manual

Page 76

PFC-4410RC • 5403550 • REV Q • 11/12

After all available outputs for the zone displayed are mapped, the display will automatically change to the next zone.

After mapping the last zone or skipping to the next function, the following will appear in the display window:

Custom Message

To change the banner message, press the middle button. If you don’t want to change the banner message press the bottom button.

SET

SELECT

Press the middle button to change banner message.

FUNCTION

Press the bottom button to skip to the next function.

If the middle button was pressed, the following will appear in the display window:

The “^” is pointing to the first character on the top line. Press the top button to scroll one direction through the character set, or

press the middle button to scroll the other direction. The entire alphabet, numbers and punctuation are included.

SET

Press the top button to scroll through the character set in one direction.

SELECT

Press the middle button to scroll in the opposite direction.

FUNCTION

Press the bottom button to enter the character displayed and to move to the next position.

After programming the top line (maximum 10 characters), continue this process for the bottom line and the initiating zones. To

keep the initiating zones as “ZONE 1”, etc., press the bottom button when they are displayed.

When finished with the last zone, the following will appear in the display window:

This allows the user to change the password. All panels are shipped from the factory with a password of 000.

SET

Press the top button to set the displayed number and move to the next space.

SELECT

Press the middle button to scroll through the numbers.

FUNCTION

Press the bottom button to skip this function.

When finished with this section, the following will appear in the display window:

Quit by returning the programming switch to the left position. The system is now ready for operation.

B A N N E R

M E S S A G E ?

N E W

P A S S W O R D = 0 0 0

P U S H

P R O G R A M M I N G

S W I T C H

B A C K

U P
