PFC-4410RC • 5403550 • REV Q • 11/12

· Supervisory Zones

· Supervisory

· Tamper

· Low Air Supervisory

· High Air

· Low Air Alarm

NOTE: Only zones programmed as Detection, Waterflow, Linear Heat, Manual Release, and Low Air

Alarm can be mapped to outputs programed as release.

· Remote Annunciator Output for connection to RA-4410RC:

· RS-485 communication, (2-wire shielded cable required)

· Regulated 24VDC annunciator power

· Two Supervisory Zones, Class B (Style B). This zone can be set up for any of the following:

· Supervisory

· Tamper

· Low Air Supervisory

· High Air

· * Abort (Supervisory zone 1 only)

NOTE: * Abort on a water-based extinguishing system is not a UL Listed function.

· Four Class B (Style Y) Output circuits. Each output can be set up for any of the following:

· Notification Appliance circuit, (First or Second alarm notification in chemical extinguishing mode)

· Releasing circuit

· Pulse Releasing circuit (called eAEROSOL, 1/16th sec on 15/16th sec off. Chemical mode only, will cycle 200

times before turning off)

· Supervisory Bell circuit

· Trouble Bell circuit

· One Abort Circuit (Available in Chemical Mode only) Programmable for four different operating modes

· ULI – Stops the pre-discharge timer at 10 seconds

· IRI – Abort must be activated before the second alarm is received

· NYC (not UL listed) A one time operation that adds 90 seconds to the remaining predischarge time

· * 30 Second Abort (stops or reverts the pre-discharge timer at 30 seconds)

NOTE: * Not a UL Listed function

· Fifteen Standard Programs for water based systems or custom program capability

· Nine Standard Programs for Chemical based systems or custom program capability

· User selectable between Water Based or Chemical Extinguishing

· Releasing Zones can be set up for either normal or cross zoning operation

· Discharge time is user selectable for either 7, 8, 9, 10, 20 minutes or continuous in the custom program

· All circuits inherently power limited per NEC 760 and UL 864 Section 14.4

· Initiating Circuit Disable feature

· Output Disable feature

· One-Man Walktest feature with automatic 30 minute restoration and releasing circuit disable

· Class B (Style B) Abort circuit available in Chemical mode. Three Abort modes available

· Pre-Discharge timer from 0-60 seconds available in Chemical mode only

· Manual Release 0-30 seconds predischarge timer in Chemical Mode only

· Notification Appliance Circuits can be programmed to operate upon 1

or 2

alarm in Chemical Mode for pre-discharge

signal

· Diagnostic Indicators

Abort does not function and has no effect on panel operation

from zones programmed as MANUAL RELEASE.

An eAEROSOL output shall only be used with Aerosol

Generators (listed on page 90). Using a standard releasing

circuit for an Aerosol Generator can prevent the Aerosol

agent from being released.
