Potter PFC-4410RC - Manual (Page 18)

18
PFC-4410RC • 5403550 • REV Q • 11/12
There is no capability to back up screens in the program mode. If a mistake was made during programming, move the program
switch back up, then move it down and start from the beginning.
To exit the program mode at any time, move the Program Switch to the left.
When the programming switch is down (see Panel Visual Display) the following will appear in the display window:
History
To examine the HISTORY press the top button, the display window will show the time and date of the last event or action. To skip
to the next function or to exit history, press the FUNCTION (bottom) button.
SET Press the top button to discover the time and date of the last event or action and to scroll forward.
SELECT To scroll back, press the middle button.
FUNCTION To exit or skip HISTORY, press the bottom button.
To program, push the Program Switch down.
L O O K A T
H I S T O R Y ?
S E T T I M E ?
0 1 / 0 5 / 2 0 0 7
M I N U T E S 0 5 : 1 9 : 3 5
P A S S W O R D = 0 0 0
^
After pressing the FUNCTION (bottom) button the following will appear in the display window:
Date and Time
SELECT To change the time, press the middle button.
FUNCTION To exit to the next function, press the bottom button.
If the middle button is pushed, the date and time will appear in the display window:
The date is shown at the top and the time at the bottom of the display window. “MINUTES” indicates that the user can now
change the minutes.
SET Pressing the top button will decrease the minutes.
SELECT Pressing the middle button will increase the minutes.
FUNCTION When finshed setting the minutes, Press the bottom button. The minutes will change to hours.
Continue this process and change the DAY, MONTH and YEAR. When you have finished changing the year, press the
FUNCTION (bottom) button. A display similar to the following will appear:
