27
PFC-4410RC • 5403550 • REV Q • 11/12
Program #3 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change. (All panels are shipped with a 000
password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #3”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch back up.
Description: Dual hazard, combined release.
Inputs: 2 detection zones, 1 waterflow zone, 1 manual release zone, 2 supervisory zones
Outputs: 1 general alarm bell, 1 supervisory bell, 2 solenoid release circuits
Operation: Activation of either detection zone or the manual release zone will activate both solenoid release outputs and the
general alarm bell.
Activation of the waterflow zone will operate the general alarm bell.
Activation of the supervisory zone will operate the supervisory bell output.
When either zone 1, 2 or 4 is in alarm - outputs #1 (general alarm), #3 and #4 (solenoid release) will operate.
When zone 3 is in alarm - output #1 (general alarm) will operate.
When the supervisory zone is activated - output #2 (supervisory bell) will operate.
PROGRAM #3
ZONES
SUP 1 SUP 2 #1 #2 #3 #4
OUTPUTS Supervisory Detection Detection Waterflow Manual
Release
#1 ALARM INDICATING X X X X
#2 SUPERVISORY X X
#3 RELEASE X X X
#4 RELEASE X X X
