31
PFC-4410RC • 5403550 • REV Q • 11/12
Program #5 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change. (All panels are shipped with a 000
password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #5”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch up.
Description: Single hazard, 3 zone with trouble bell.
Inputs: 2 detection zones, 1 waterflow zone, 1 manual release zone, 2 supervisory zones
Outputs: 1 general alarm bell, 1 trouble bell, 1 supervisory bell, 1 solenoid release circuit
Operation: Activation of either detection zone or the manual release zone will operate the solenoid release circuit and the
general alarm bell.
Activation of the waterflow zone will operate the general alarm bell.
Activation of the supervisory zone will operate the supervisory bell.
A trouble condition (low battery, wire problem, etc.) will operate the trouble bell.
When either zone 1, 2 or 4 is in alarm - outputs #1 (general alarm) and #4 (solenoid release) will operate.
When zone 3 is in alarm - output #1 (general alarm) will operate.
When the supervisory zone is activated - output #3 (supervisory bell) will operate.
When the panel is in a trouble condition - output #2 (trouble bell) will operate.
PROGRAM #5
ZONES
SUP 1 SUP 2 #1 #2 #3 #4
OUTPUTS Supervisory Detection Detection Waterflow Manual
Release
#1 ALARM INDICATING X X X X
#2 TROUBLE
#3 SUPERVISORY X X
#4 RELEASE X X X
