21
PFC-4410RC • 5403550 • REV Q • 11/12
PFC-4410RC Standard Program Information
The PFC-4410RC has 24 standard programs which are detailed in the following pages. Selecting one of these programs will auto-
matically program every function of the panel except the custom
banner and zone message functions.
NOTES:
The release discharge time is continuous for all 24 programs.
In the chemical extinguishing programs the pre-discharge timer defaults to 60 seconds, manual release pre-discharge timer de-
faults to 30 seconds, the abort mode defaults to UL.
The following is an explanation of how the various programs operate and information about the types of devices that are to be
connected to the input and output zones.
If none of the standard programs are acceptable for the installation required, select the custom program #0 then press the SET
(top) button. This will allow the user to custom program the panel. Turn to page 72 for custom program information.
Type Description
Alarm Zones Detection Smoke Detectors, Spot Type Heat Detectors
Waterflow PS10 Pressure Switch
Linear Heat Cable Type Heat Detectors
Manual Release Pull Stations
Supervisory Zones Supervisory Valve Tamper, Low Air, High Air, Room Temperature
Low Air supervisory Low Air Switch
High Air High Air Switch
Tamper Valve Tamper Switch
Low Air Alarm * PS10, PS40
Outputs Alarm 24VDC Bells, Horns, Strobes, to indicate an
alarm condition.
Release Solenoid Valve, Squib, Releasing Mechanism
eAEROSOL Aerosol Generator
Supervisory 24VDC Bells, Horns, Strobes, to indicate a
supervisory condition.
Trouble 24VDC Bells, Horns, Strobes, to indicate a
trouble condition.
To program the PFC-4410RC to operate with one of the following 24 standard programs:
The water based extinguishing programs are numbered 1-15. The chemical extinguishing programs are numbered 20-28. A
description, theory of operation, and wiring diagrams for all standard programs start on the next page.
1. Press SELECT (center) button to scroll to the program number (#1 through #15, #20 through #28) you desire.
2. Press SET (top) button.
3. Turn to page 76 to program the banner message and to finish programming the panel.
SET After selecting the proper program number, press the top button to set the program and move to the
next function.
SELECT Press the middle button to scroll through the programs.
FUNCTION Press the bottom button to skip to the next function.
After selecting the desired program number with the middle button, SET (top button) must be
pressed to set the program.
*Not available on Supervisory Zones: Sup 1 or Sup 2.
