Program #8 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change. (All panels are shipped with a 000
password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #8”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch up.
Description: Single hazard, dual zone.
Inputs:
1 supervisory zone, 1 low air supervisory zone, 2 detection zones, 1 tamper switch zone, 1 waterflow zone
Outputs:
1 general alarm output, 2 waterflow outputs, 1 solenoid release circuit
Operation: Activation of either detection zone will operate the general alarm bell and the solenoid release circuit.
Activation of the waterflow zone will operate the general alarm bell and both of the waterflow bell outputs.
When zone 1 or zone 2 is in alarm - output #1 (general alarm) and output #3 (solenoid release) will operate.
When either zone 3 or the supervisory zone is activated - the panel will be in a supervisory condition, no
outputs will be activated.
When zone 4 is in alarm - output #1 (general alarm) and outputs #2 and #4 (both waterflow bells) will operate.
PROGRAM #8
ZONES
SUP 1
SUP 2
#1
#2
#3
#4
OUTPUTS
Supervisory
Low Air
Supervisory
Detection
Detection
Valve
Tamper
Waterflow
#1 ALARM INDICATING
X
X
X
#2 ALARM INDICATING
X
#3 RELEASE
X
X
#4 ALARM
X
