29
PFC-4410RC • 5403550 • REV Q • 11/12
Program #4 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change. (All panels are shipped with a 000
password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #4”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch up.
Description: Dual hazard, split release.
Inputs: 2 detection zones, 1 waterflow zone, 3 supervisory zones
Outputs: 1 general alarm bell, 1 supervisory bell, 2 solenoid release circuits
Operation: Activation of detection zone #1 will operate solenoid release circuit #1 (output #3) and the general alarm bell.
Activation of detection zone #2 will operate solenoid release circuit #2 (output #4) and the general alarm bell.
Activation of zone #3 (Waterflow) will operate output #1 (General Alarm).
Activation of either supervisory zone will operate the supervisory bell.
When zone 1 is in alarm - output #1 (general alarm) and output #3 (solenoid release #1) will operate.
When zone 2 is in alarm - output #1 (general alarm) and output #4 (solenoid release #2) will operate.
When either zone 4 or the supervisory zones are activated - output #2 (supervisory bell) will operate.
PROGRAM #4
ZONES
SUP 1 SUP 2 #1 #2 #3 #4
OUTPUTS Supervisory Detection Detection Waterflow Supervisory
#1 ALARM INDICATING X X X
#2 SUPERVISORY X X X
#3 RELEASE X
#4 RELEASE X
