Program #26 Mode

1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4.To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET

button to move to the next digit. After entering the third number the display will change.
(All panels are shipped with a 000 password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #26”.
7. Press the SET button.
8. Press the SELECT button to change the pre-discharge time.
9. Press the SET button to enter the pre-discharge time displayed.
10. Preset the SELECT button to change the manual release pre-discharge time. See page 11 for abort mode selections.
11. Press the SET button to enter the manual release pre-discharge time displayed.
12. Press the SELECT button to change the abort mode.
13. Press the SET button to enter the abort mode displayed.
14. The panel is completely programmed except for the custom banner and zone messages. Move the program switch back up.

Description:

Single Hazard, 2 detection zones cross-zoned to 2 release circuits. A manual station zone. Also first and second

alarm notification circuits.

Inputs:

1 supervisory zone, 3 detection zones, 1 manual station zone, 1 abort circuit

Outputs:

2 general alarm, 2 eAEROSOL circuits

Operation:

Activation of either detection zones 1 or 2 will activate the alarm output #1

Activation of both detection circuits at the same time will activate the alarm outputs #1, #2 and start the pre-

discharge timer for the eAEROSOL circuits output #3 and #4

Activation of zone 3 will operate output #1

Activation of the manual release Zones 4 will operate output #2 and start the pre-discharge timer for the

eAEROSOL circuits output #3 and #4.

When either zone 1 or 2 is in alarm, output 1 will operate

When both zones 1 and 2 are in alarm at the same time, outputs #1,2 will operate and the pre-discharge timer for

outputs #3 and #4 will start

When zone 3 is in alarm, output #1 will operate

When zone 4 is in alarm, output 2 will operate and the manual release pre-discharge timer for outputs #3 and #4 will

start

PROGRAM #26

ZONES

SUPERVISORY 2

OUTPUTS

Supervisory

Detection

Manual Release

#1 FIRST ALARM

#2 SECOND ALARM

#3 eAEROSOL

#4 eAEROSOL

SUP 1 defaults to abort

XX = Cross-Zoned
