Potter PFC-4410RC User Manual
Page 75
75
PFC-4410RC • 5403550 • REV Q • 11/12
Where “” is the number of the releasing circuit output.
Normal/Cross-Zoning
Each releasing circuit can be set up for the normal or cross zoned operation. In NORMAL operation, any alarm initiating zone
including LOW AIR ALARM mapped to a releasing output must be in alarm before the output is activated. In cross zoned
operation ALL initiating zones mapped to the releasing circuit must be in alarm before the output is activated. An initiating zone
previously described as “MANUAL RELEASE” will override the cross zoning feature.
SET
Press the top button to set the operation displayed.
SELECT
Press the middle button to toggle between NORMAL and CROSS ZONED.
FUNCTION
Press the bottom button to skip to the next function.
After selecting normal or cross zone operation the next function will be displayed as follows:
Releasing Output Time
This allows the user to determine how long the releasing circuit is energized upon alarm. The available
times are 7, 8, 9, 10 and 20 minutes and continuous (Potter recommends Continuous). Use the middle button to scroll through the
possible options and the top button to set that option. Press the bottom button to skip to the next function.
SET
Press the top button to set the time displayed.
SELECT
Press the middle button to scroll through the available time.
FUNCTION
Press the bottom button to skip to the next function.
After choosing the discharge time, a display similar to the following will appear:
This display is where the outputs are mapped to the initiating zones. Any output that was previously described as “RELEASING”
or “ALARM INDICATING” can be mapped to any initiating zones that were described as alarm zones, including zones
programmed as LOW AIR ALARM.
Any initiating zone that was described as supervisory will automatically be mapped to outputs described as “SUPERVISORY
BELL”, including zones programmed as LOW AIR ALARM. The “v” is pointing to the first available output for the zone
indicated on the display. If the output number is displayed, it is turned on for that zone. If the number is not displayed, it is turned
off. If an output is not available for that zone, i.e. “SUPERVISORY BELL”, the “v” will skip to the next available output.
SET
Press the top button to set the output to the zone displayed and move to the next available output.
SELECT
Press the middle button to turn the output either on or off (the output number will be displayed when
turned on).
FUNCTION
Press the bottom button to skip to the next function.
D I S C H A R G E
T I M E
C O N T I N U O U S
Z O N E
1
V
O U T P U T S :
1
2
3
4
