25
PFC-4410RC • 5403550 • REV Q • 11/12
Program #2 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change. (All panels are shipped with a 000
password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #2”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch up.
Description: Single hazard, cross zone with manual station override.
Inputs: 2 detection zones (cross zoned), 1 waterflow zone, 1 manual release zone, 2 supervisory zones
Outputs: 1 general alarm bell, 1 waterflow bell, 1 solenoid release circuit, 1 supervisory bell
Operation: Activation of both detection zones at the same time, or activation of the manual release zone will operate the release
output and the general alarm output.
Activation of one detection zone will operate the general alarm output.
Activation of the waterflow zone will operate the waterflow bell output.
Activation of the supervisory zone will operate the supervisory bell output.
When zone 1, 2 or 4 is in alarm - output #1 will operate (general alarm bell).
When zone 3 is in alarm - output #2 will operate (waterflow bell).
When both zones 1 and 2 are in alarm at the same time - output #3 will operate (solenoid release).
When zone 4 is in alarm - outputs #3 (solenoid release) and #1 (general alarm) will operate.
PROGRAM #2
ZONES
SUP 1 SUP 2 #1 #2 #3 #4
OUTPUTS Supervisory Detection Detection Waterflow Manual
Release
#1 ALARM INDICATING X X X
#2 ALARM INDICATING X
#3 RELEASE XX XX X
#4 SUPERVISORY X X
XX = Cross-Zoned
