49
PFC-4410RC • 5403550 • REV Q • 11/12
Program #14 Mode
1. Apply power to panel.
2. Move the program switch down.
3. Press the FUNCTION (bottom) button until the display reads “PASSWORD = 000”.
4. To enter a password, press the SELECT button until the proper number is displayed above the ^ symbol, then press the SET
button to move to the next digit. After entering the third number the display will change.
(All panels are shipped with a 000 password.)
5. Press the FUNCTION (bottom) button until the display reads “PROGRAM #0”.
6. Press the SELECT button until the display reads “PROGRAM #14”.
7. Press the SET button.
8. The panel is completely programmed except for the custom banner and zone messages. Move the program switch back up.
Description: QRS System 4 Manual Station zones and 4 Release Outputs mapped 1 to 1
Inputs: 4 Manual Station zones, 2 Supervisory zones
Outputs: 4 release circuits
Operation: Activation of detection zone 1 will activate release output #1
Activation of detection zone 2 will activate release output #2
Activation of detection zone 3 will activate release output #3
Activation of detection zone 4 will activate release output #4
note:
After initially setting the PFC-4410RC to program 14 and returning the program switch to the normal UP position:
When setting or resetting the QRS, slide the program switch down. The display will read: OK TO CHARGE SYSTEM. Charge
the system to normal operating pressure. After the system reaches normal operating pressure, press the SET button and slide the
program switch back up.
Remember to wait 60 seconds after the system reaches normal operating pressure before testing the QRS.
PROGRAM #14
ZONES
SUP 1 SUP 2 #1 #2 #3 #4
OUTPUTS Supervisory Detection Detection Detection Detection
#1 RELEASE X
#2 RELEASE X
#3 RELEASE X
#4 RELEASE X
W
hen the program sWitCh is in the doWn position
,
the panel is inoperative
. n
one of the outputs or inputs Will
operate
. n
o
Qrs
Will operate
. t
he sprinkler system Will operate as a regular dry pipe system
.
