EVCO S.p.A. Vcolor 338 L | Installer manual ver. 2.0 | Code 144VC338LE204
page 62 of 66
digital inputs for high voltage contact
Power supply: 230 VAC.
Protection: none.
Analogue outputs:
1 0-10 V output for fan management (in this case, an external speed regulator
must be used).
Digital outputs:
13 outputs (electromechanical relays):
- 1 x 1 A res. @ 250 VAC SPST type (K1) for environment
temperature regulation management
- 1 x 1 A res. output @ 250 VAC SPST type (K2) for air vent
management
- 1 x 1 A res. output @ 250 VAC SPDT type (K8) for direct steam
injection management
- 1 x 4 A res. output @ 250 VAC SPST type (K9) for environment
light management
- 1 x 1 A res. output @ 250 VAC SPST type (K7) for management of
the technical compartment fan
- 1 x 1 A res. output @ 250 VAC SPST type (K5) configurable
(default setting, for fan left drive management)
- 1 x 1 A res. output @ 250 VAC SPST type (K4) configurable
(default setting, for fan right drive management)
- 1 x 1 A res. output @ 250 VAC SPST type (K3) configurable
(default setting, for fan speed management)
- 1 x 1 A res. output @ 250 VAC SPST type (K6) for rack rotation
management
- 1 x 1 A res. output @ 250 VAC SPST type (K13) configurable
(default setting, for cleaning water valve management)
- 1 x 1 A res. output @ 250 VAC SPST type (K12) configurable
(default setting, for liquid detergent injection management)
- 1 x 1 A res. output @ 250 VAC SPST (K11) configurable (default
setting, for cleaning fluid discharge management)
- 1 x 1 A res. output @ 250 VAC SPDT (K10) configurable (default
setting, for rinse aid injection management).
The maximum current allowed on the loads is 3 or 4 A (please refer to the
wiring diagram).
Displays:
7 inch, 16k colour TFT touch-screen graphical display with
800 x 480 pixel resolution.
Type 1 or Type 2 actions: Type 1.
Complementary features of Type 1 or Type 2
actions:
C.
