EVCO S.p.A.
Vcolor 338 L | Installer manual ver. 2.0 | Code 144VC338LE204
page 17 of 66
The following drawing illustrates the layout of the device user interface rear panel.
The following table illustrates the meaning of the rear parts of the device user interface.
PART
MEANING
1
USB port
2
MODBUS communication port
3
dip switch to activate the MODBUS RS-485 port terminal resistor
4
communication port with the user interface (power supply)
5
dip switch
6
ground
For further information, see the next chapters.
