EVCO EVCLC33DJ2 - Manual (Page 20)

EVCO S.p.A. Vcolor 338 L | Installer manual ver. 2.0 | Code 144VC338LE204
page 20 of 66
5 COMMISSIONING
5.1 Commissioning
Operate as indicated:
1. Install the device using the methods illustrated in chapter 2 “DIMENSIONS AND INSTALLATION”, following all warnings
given in paragraph 2.3 “Installation warnings”.
2. Connect the device electrically using the methods illustrated in chapter 3 “ELECTRIC CONNECTION”, following all warnings
given in paragraph 3.2 “Warnings for the electric connection”, without connecting the power supply and the mains
electricity.
3. Connect the device power supply: a splash screen will be displayed for a few seconds.
4. Set the time, the date and the day of the week; see paragraph 16.1 “Setting the time, date and day of the week”.
5. Configure the device with the procedure illustrated in the paragraph 16.2 “Setting the configuration parameters”.
The following table illustrates the meaning of the configuration parameters; the parameters are listed according to the
appropriate configuration sequence.
PARAM. MEANING FACTORY SETTING
P0
Probe type
0 = thermocouple J (only in the J/K versions)
1 = thermocouple K (only in the J/K versions)
2 = Pt 100 (only in the Pt 100 versions)
0
P1
Unit of measurement
0 = °C
1 = °F
0
P2
Enabling the needle probe
1 = YES
0
F0
Type of fan management
0 = in “on/off” mode and at single speed
1 = in “on/off” mode, with single speed and with inversion of the direction of
rotation of the fan
2 = in “on/off” mode, with dual speed and with inversion of the direction of
rotation of the fan
3 = in modulating mode and with inversion of the direction of rotation of the
fan
0
t0
Steam generation mode
0 = direct
1 = with an external humidifier
2 = combined (i.e. direct and with external humidifier)
0
u0
Air vent output contact type
0 = normally open (air vent opens when the contact is closed)
1 = normally closed (air vent opens when the contact is open)
0
u1
Utility managed by the air vent output
0 = ELECTROVALVE ON/OFF
1 = MOTORISED ELECTROVALVE - in this case the u2, u3 and u4 parameters
will assume significance
0
