MANAGEMENT OF UTILITIES

6.1

Preliminary notes

This paragraph illustrates the activity of the utilities during

normal operation.

To know the main consequences of an alarm, see chapter 16

“ALARMS”.

6.2

Temperature regulation

The output is on until the environment temperature reaches

the work set-point and is switched back on when the

temperature drops below the value established with the

parameter r0 (i.e. "working set-point - r0").

To set the work set-point, see paragraph 8.2 “Setting the

cooking cycle”; to set the configuration parameters, see

paragraph 16.2 “Setting the configuration parameters”.

6.3

Steam injection

The steam generation mode depends on parameter t0, as

follows:

-

if the parameter t0 is set at 0, the steam will be

generated in direct mode.

-

if the parameter t0 is set at 1, the steam will be

generated with an external humidifier

-

if the parameter t0 is set at 2, the steam will be

generated in combined mode (i.e. direct and with

external humidifier); in this case the temperature

established with parameter t12 determines the

temperature above which the steam generated in

direct-mode will be injected and below which the

steam generated with an external humidifier will

be injected (referring to the temperature detected

by the environment probe).

The parameter t1 establishes the cycle time for the injection of

the steam generated in direct mode and the parameter t2 the

duration of the injection of the steam generated with the same

mode corresponding to the maximum humidification.

The parameter t6 establishes the cycle time for the injection of

the steam generated with external humidifier and the

parameter t7 the duration of the injection of the steam

generated with the same mode corresponding to the maximum

humidification.

To set the humidification, see paragraph 8.2 “Setting the

cooking cycle”; to set the configuration parameters, see

paragraph 16.2

“Setting the configuration parameters”.

6.4

Air Vent

The utility managed by the air vent output depends on

parameter u1, as follows:

-

if the parameter u1 is set at 0, the utility will be

an on/off electrovalve

-

if the parameter u1 is set at 1, the utility will be a

motorised electrovalve

The air vent is opened automatically on conclusion of each

phase of a cooking cycle.

To set the duration of the automatic air vent opening, see the

paragraph 8.2 “Setting the cooking cycle”.

The air vent is also opened/closed by touching the “manual”

area.

6.5

Room light

The environment light is switched on/off by touching the

reference area:

.

6.6

Technical compartment fan

The technical compartment fan is on until the temperature of

use of the control module reaches the temperature established

with parameter F6 and is switched back on when the

temperature rises above that established with parameter F7

(i.e. “F6 + F7”).

To set the configuration parameters, see paragraph 16.2

“Setting the configuration parameters”.

6.7

Fan

The type of ventilation management depends on parameter

F0, in the following way:

-

if the parameter F0 is set at 0, ventilation will be

managed in “on/off” mode and at single speed

-

if the parameter F0 is set at 1, ventilation will be

managed in “on/off” mode and at single speed and

with inversion of the fan rotation direction

-

if the parameter F0 is set at 2, ventilation will be

managed in “on/off” mode and at dual speed and

with inversion of the fan rotation direction

-

if the parameter F0 is set at 3, ventilation will be

managed in modulating mode and with inversion

of the fan rotation direction

If parameter F0 is set at 0, 1 or 2, parameter F1 will establish

the duration of fan switch off due to the inversion of the

direction of rotation of the same and parameter F2 that of fan

switch-on for every direction of rotation.

If parameter F0 is set at 3, the parameters F4 and F5 will

establish the minimum and the maximum fan speed, the

parameter F8 will establish the minimum fan speed that can

be set on a cooking cycle.

To set the fan speed, see paragraph 8.2 “Setting the cooking

cycle”; to set the configuration parameters, see paragraph

16.2 “Setting the configuration parameters”.
