A1
0
500
°C/°F (2)
0
temperature above which the maximum temperature alarm is
activated (referring to the temperature detected by the environment
probe); see also A0 and A3
A2
0
240
min
0
maximum temperature alarm delay
A3
0
2
- - -
0
maximum temperature alarm type
0 = no alarm
1 =
absolute (i.e. A1)
2
=
relative to the work set-point (i.e. “work set-point + A1”)
A4
0
80/175
°C/°F (2)
70
temperature above which the use temperature alarm is activated
(referring to the temperature of use of the control module)
0 = no alarm
PARAM.
MIN.
MAX.
U.M.
DEF.
DIGITAL INPUTS
i0
0
1
- - -
0
type of door micro switch input contact
0
=
normally open (input active with closed contact)
1
=
normally closed (input active with open contact)
i1
0
1
- - -
0
type of circuit breaker protection input
0
=
normally open (input active with closed contact)
1
=
normally closed (input active with open contact)
i2
0
1
- - -
0
reserved
i3
0
1
- - -
0
type of safety thermal protection input
0
=
normally open (input active with closed contact)
1
=
normally closed (input active with open contact)
i4
0
1
- - -
0
type of electric absorption input contact
0
=
normally open (input active with closed contact)
1
=
normally closed (input active with open contact)
PARAM.
MIN.
MAX.
U.M.
DEF.
DIGITAL OUTPUTS
u0
0
1
- - -
0
type of air vent output contact
0
=
normally open (air vent opens with closed contact)
1
=
normally closed (air vent opens with open contact)
u1
0
1
- - -
0
utility managed by the air vent output
0
=
ELECTROVALVE ON/OFF
1
=
MOTORISED ELECTROVALVE - in this case the u2, u3 and u4
parameters will assume significance
