16.3
List of configuration parameters
The following table illustrates the meaning of the device configuration parameters.
PARAM.
MIN.
MAX.
U.M.
DEF.
ANALOGUE INPUTS
P0
0
2
- - -
0
probe type
0
=
thermocouple J (only in the J/K versions)
1
=
thermocouple K (only in the J/K versions)
2
=
Pt 100 (only in the Pt 100 versions)
P1
0
1
- - -
0
temperature unit of measurement (1)
0
=
°C
1
=
°F
P2
0
1
- - -
0
enabling the needle probe
1
= YES
P3
0
2
- - -
0
enabling the cooking fumes /condenser water drain probe
0
=
probe disabled
1
=
fumes probe
2
=
water drain probe
CA1
-25/-50
25/50
°C/°F (2)
0
environment probe offset
CA2
-25/-50
25/50
°C/°F (2)
0
needle probe offset
CA3
-25/-50
25/50
°C/°F (2)
0
fumes probe offset
PARAM.
MIN.
MAX.
U.M.
DEF.
MAIN REGULATOR
r0
1
99
°C/°F (2)
5
work set-point differential (referring to the temperature detected by
the environment probe)
r1
0
r2
°C/°F (2)
0
work set-point differential (referring to the temperature detected by
the environment probe)
r2
r1
500
°C/°F (2)
300
maximum work set-point (referring to the temperature detected by
the environment probe)
r3
r1
r2
°C/°F (2)
130
work set-point for factory setting (referring to the temperature
detected by the environment probe); see also r0
r4
0
r5
°C/°F (2)
0
minimum set-point at the core (referring to the temperature
detected by the needle probe)
r5
r4
500
°C/°F (2)
100
maximum set-point at the core (referring to the temperature
detected by the needle probe)
r6
r4
r5
°C/°F (2)
30
work set-point at the core for factory setting (referring to the
temperature detected by the needle probe)
