VR-aOaO/Vn-20BO/KRF-VBaв 1 0/KRF-V777 1 о [En/K]
Make connections as shown below.
lioSicLiryr“® ***^'^’ '*'■ ^'9"^' ^yp® detected
When connecting the related system components, be sure to also refer to the instruction manuals supplied with the
components you are connecting. ^
Do not connect the power cord to a wail outlet until all connections are completed.
The connected components are given as examples because
the available models vary depending on marketing areas.
Connect components capable of output­
ting Dolby Digital (AC-3| or standard PCM
format digital signets.
LASER DISC RF DEMODULATOR (DEM-9991Di
Note : Only required if you wi,sh to fslay Laser Discs
in the Dolby Digital (AC-31 format
DIGITAL OLfT I
(COAXiALi
To connect an LD player with a Dolby Digital ¡AC-3) RF OUT or
DIGITAL OUT (Some LD player have a ,e>CM Digital Outputs, in this case
the customer doesn't need the DEM-9991D,i
Connect the LD piayerto the (optional! KENWOOD LASER DISC RF
DEMODULATOR iDEM-9991Dj, Then connect the demodulator to
the DIGITAL IN (VIDE04 COAXIAL).
To connect the digita! output from an LD player, egnnect it either to
the DIGITAL INPUT OPT. |®1 or DIGITAL INPUT COAX, (Cl;) jack
Connect the video signal and analog audio signals to the VIDEO 4 lacks.
(See "Connecting of video components" )
’
D igital OUTT'; 'i
lOPTICALi ’
DIGITAL OUTS'!
(COAXIAL)
AC-3 RFOUT
(COAXIALI
DIGITAL OÜT®
¡COAXIAL)
!,....Г -■
0 T ^________
© • о ехэгзо} ■----------
--- j f 4. C Ó !
lrv-t-юо oO
Note : Connect either ® or (5;,
Should not be connected both
To connect an DVD player
with a DIGITAL OUT
DIGITAL OUT Ф
(OPTICAU
Connect the video signal, S Video signal and
analog audio signals to the sarne selector
(INPUT) jacks.
[See "Connecting of video components" )
Use either the (D (COAXIAL! or @ (OPTICAL) jack for the connection of a DVD player.
To the VIDEO 4 COAXIAL jack, connect the input from the DIGITAL OUT (D (COAXIAL) jack of a DVD player or the DIGITAL
OUT @ (COAXIAL) jack of the DEM-9991D,
LASER DISC RF DEMODULATOR DEM-999W (Optional)
@
KENWOOD
JMB cac M оемсепАЛ'Оа
'"L..gi| PDWER Place the power supply away from the demodulator, receiver,
and any antennas.
О POWER switch
Use to switch the POWER OFF/POWEH ON (OPT./ COAX.).
With the OPT or COAX, position, the input is switched auiornati-
cally to the Dolby Digital (AC-3) RF input whenever the Dolby Digital
(AC'3) RF signal is input.
® POWER indicator
Lights (red) when the power switch (O! Is set to ON (OPT,/ COAX ).
© RF LOCK indicator
Lights when a Dolby Digital (AC-3) RF signal is input to the RF INPUT
(AC-3 RF INPUT) jack (©). (This indicator isextinguished when a digitai
input IS in use.)
О DIGITAL OUTPUT COAX. (COAXIAL)
Connect this jack to the VIDE04 COAXIAL (DIGITAL IN), jack on your
Recievet. It outputs Dolby Digitai (AC-3) coaxial digital signals when
the POWER (©) is set to COAX, and a Dolby Digital (AC-3) RF signal
is input to the RF INPUT (AC-3 RF INPUT) jack (0).
© RF INPUT AC-3 RF (Dolby Digital RF)
Connect this jack to the Doiby Digital (AC-3) RF OUTPUT jack on your
LD player.
© DIGiTAL INPUT COAX. (COAXIAL)
Connect this jack to the COAXIAL OUTPUT jack on your LD player
© DIGITAL INPUT OPT. (OPTICAL)
Connect this jack to The OPTICAL OUTPUT jack on your LD player.
• When there are simultaneous inputs through the RF INPUT (AC-3 RFI
jack and DIGITAL INPUT jack, the input through RFiNPUT(AC-3 RFI is
given the priority,
©DC IN 12V jack
Connect this jack to the AC adaptor supplied with your demodulator.
Connect the AC adaptor to a wail outlet after completing all of the
other connections.
