Kenwood KAC-748 User Manual
Instruction manual, Mode d’emploi, Manual de instrucciones
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
KAC-848
KAC-748
4-CHANNEL POWER AMPLIFIER ► Page 2-11
INSTRUCTION MANUAL
AMPLIFICATEUR DE PUISSANCE 4 CANAUX ► Page 12-21
MODE D’EMPLOI
AMPLIFICADOR DE POTENCIA DE 4 CANALES ► Page 22-31
MANUAL DE INSTRUCCIONES
KENWOOD CORPORATION
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help
you obtain the best performance from your new power amplifier.
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call^upon your
KENWOOD dealer for information or service on the product.
Mode! KAC-848/748 Serial number_____________ •
© PRINTED IN USA B64-1350-00 (KM)
