vR-soíaa/VR-aoBO/KRF-vaaei o
A Caution: Read this page carefuily to ensure safe operation.
AUDIO section
Rated Output power during STEREO operation
100 watts per channel minimum RIWS, both channels driven, at
6 D from 20 Hz to 20 kHz with no more than 0.03 % total
harmonic distortion.(FTC)
Rated output power during SURROUND operation
FRONT
dkHz, 0.7% T.H.D. at 6 O)................. . 100 W + 100
W
CENTER
(1kHz, 0.7% T.H.D. at 6 Q!................ ..................... 100 W
SURROUND
(IkHz, 0.7% T.H.D. at 6 Q1........................ 100 W + 100 W
Totai harmonic distortion............ 0.004% i1 kHz, 50 W, 6 fl)
Frequency response (IHF'78)
CD ..................................... 5 Hz ~ 80 kHz, +0.5 dB, -3 dB
Signal to noise ratio (IHF'66)
PHONO (MM)......................................... . 77 dB
CO ................................................. ..........................90 dB
Input sensitivity / impedance
PHONO (MM)............................................ 2.5 mV / 47 kQ.
CO................ .......................................... . 200 mV / 47 k£2
Output level / impedance
TAPE REC ............................................... 200 mV / 220 O
PRE OUT (CENTER, SURROUND, SUBWOOFER)
............ .............................................................. 1 V / 1 kQ
Tone control
BASS......................................................±7 dB fat 100 Hz)
TREBLE....... .......................................... ±7 dB (at 10 kHz)
LOUDNESS control
VOLUME at -40dB level... +7 dB(100 Hz), +4 dBilO kHz)
DIGITAL AUDiO section
Sampling frequency.......... ............ 32 kHz, 44.1 kHz, 48 kHz
Input level / impedance / wave length
Optical................... -15 dBm - -21 dBm, 660 nm aSOnm
Coaxial.................................................... ..0.5 Vp-p / 75 Q
VIDEO section
VIDEO inputs / outputs
VIDEO (composite).................. ................... 1 Vp-p / 75 Q
FM tuner section
Tuning frequency range....................... 87.5 MHz ~ 108 MHz
Usable sensitivity (MONO)
...... 1.6pV (75 QÌI 15.2 dBf (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity
STEREO .............. ...................... 31.6pV (75 Q)/ 41.2 dBf
Total harmonic distortion (1 kHz)
MONO............................................... 0.3 % (65 dBf input)
STEREO............................................ 0.6 % (65 dBf input)
Signal to noise ratio (1 kHz, 75 kHz DEV.)
MONO............................................... 75 dB (65 dBf input)
STEREO............................................ 68 dB (65 dBf input)
Stereo separation (1 kHz)............................... ..... ........ 38 dB
Selectivity (±400 kHz)..................................................... 70 dB
Frequency response ......... .30 Hz ~ 15kHz,+0.5 dB, -3.0 dB
AM tuner section
Tuning frequency range
10 kHz step.......................................530 kHz ~ 1,700 kHz
Usable sensitivity (30% mod., S/N 20 dB)
........................................................... 16pV/(600 pV/m)
Signal to noise ratio (30 % mod. 1 mV input).............. 50 dB
Relay and IRIN/OUT section
IR RECEIVER IN terminal
Maximum output current..
Operating voltage................
Output impedance...............
IR OUT LCD REMOTE terminal
Maximum output current..
Operating voltage................
Output impedance...............
Shape of plug to be connected
IR RECEIVER !N IR OUT LC
Stereo TTum p!ug Stereo r
Siseve ^ Tip Sleeve
ctFzrn
Ring .n' Ri
IR IN/OUT specification
Terminal IR RECEIVER IN IR OUT L
[ To Tip Signal Signal
1 To Ring Ground
j To Sleeve +12 V Ground
GENERAL
Power consumption.........................................
AC outlet
SWITCHED...... ......................2 (total 90 V
Dimensions..........................................W; 440
H ; 162
D- 391
Weight (Net)............................ ..................... 11
1, KENWOOD follows a policy of continue
in development. For this reason spec
changed without notice.
2. Fuil performance may not be exhibited
locations (below 0 deg.C).
