Cub Cadet Z-Force S Series - Manual (Page 61)

Steering
55
5. Lift the upper housing off of the lower housing.
NOTE: There is no sealant between the two housings.
They should easily slip apart. If they are stuck
together, there are three pry points cast into the
housings that can be used to separate the hous-
ings. See Figure 6.32.
6. Remove the steering rack. See Figure 6.33.
7. Remove the wear block and spring.
8. Remove the speed cam assemblies.
See Figure 6.34.
Figure 6.32
Using one of the pry
points to separate the
housings
Figure 6.33
Steering
rack
Wear block
Figure 6.34
Speed cam assemblies
