Deck belt – Cub Cadet Z-Force S Series User Manual
Page 148
Z-Force-S
142
Deck Belt
To replace the 46” deck belt:
1.
Remove the deck as describe at the beginning of
this chapter.
2.
Slide the belt off of the pulleys.
3.
Remove the spindle covers following the steps
described in the spindle section of this chapter.
4.
Loosen the belt keepers enough to allow the belt to
slip past them.
5.
Route the new belt around the pulleys.
6.
Tighten the belt keepers.
7.
Install the deck as describe at the beginning of this
chapter.
8.
Test run the mower before returning to service.
To replace the 60” deck belt:
1.
Remove the deck as describe at the beginning of
this chapter.
2.
Remove the PTO Belt by following the procedures
described in the PTO belt section of this chapter.
3.
Slide the belt off of the pulleys.
4.
Remove the spindle covers following the steps
described in the spindle section of this chapter.
5.
Loosen the belt keepers enough to allow the belt to
slip past them.
6.
Route the new belt around the pulleys.
7.
Tighten the belt keepers.
8.
Install the deck as describe at the beginning of this
chapter.
9.
Test run the mower before returning to service.
Figure 8.7
Figure 8.8
