Z-Force-S
26
Seat
To remove/replace the seat:
1. Disconnect the seat switch.
2. Remove the four nuts that hold the seat track to the
seat base using a 1/2” wrench. See Figure 4.22.
3. Lift the seat off of the base.
NOTE: The track is serviced as part of the seat and
is not available separately.
4. Remove the seat switch using a 3/8” wrench.
See Figure 4.23.
5. Install the seat by following the previous steps in
reverse order.
6. Test drive the mower in a safe area before returning
it to service.
Figure 4.22
Seat switch
Nuts
Figure 4.23
Seat switch
