Cub Cadet Z-Force S Series User Manual
Page 28
Z-Force-S
22
17.
Remove the screws that hold the front of the control
console to the front of the seat box assembly using
a T-30 torx driver and a 7/16” wrench. See Figure
4.21.
18.
Gently pull the harness through the hole in the con-
sole while lifting it off of the mower.
19.
Install the control console by following the previous
steps in reverse order.
20.
Test drive the mower in a safe area before returning
it to service.
Figure 4.14
Screws
