Maintanence Intervals
159
Oil filter
To replace the oil filter:
1. Drain the oil by following the steps described in the
previous section of this chapter.
NOTE: If replacing a damaged filter, the filter can be
removed without draining the oil.
2. Clean the area around the oil filter
3. Remove the oil filter by turning it counter-clockwise,
as seen from the right side of the mower.
See Figure 9.9.
4. Place a light coating of oil on the O-ring of the new fil-
ter.
5. Pre-fill the new filter with fresh, clean oil.
6. Thread the new filter on to the engine. Hand tighten
only.
7. Fill the engine with oil.
8. Test run the engine and check for leaks before return-
ing the mower to service.
Engine Oil Capacity
Oil filter was not removed 1.9 US qt. (1.8L)
Oil filter was removed 2.2 US qt. (2.1L)
6$(
6$(
6$(:6$(:
6$(:
ƒ) ƒ) ƒ) ƒ) ƒ) ƒ) ƒ)
ƒ& ƒ& ƒ& ƒ& ƒ& ƒ& ƒ&
Oil Chart
Figure 9.9
Oil filter
