Z-Force-S
6
Fuel tank removal/replacement
Remove/replace the fuel tank by following these steps:
1. Clamp off the fuel line between the fuel tank and the
fuel filter.
2. Disconnect the fuel line from the fuel tank at the fuel
filter.
3. Drain the fuel into an approved container.
4. Remove the fuel tank by removing the four screws
that hold it to the support brackets using a 9/16”
wrench. See Figure 2.4.
5. Install the fuel tank by following the previous steps
in reverse order.
6. Test drive the mower in a safe area before returning
it to service.
! CAUTION ! CAUTION
Gasoline and its vapors are extremely flammable. Use common sense when working around
the fuel system
Figure 2.3
Fuel filter
Fuel line from the fuel tank
Figure 2.4
Support brackets
