Z-Force-S
36
11. Remove the nut and bolt that hold the front of the
transmission to the frame cross member using a
pair of 1/2” wrenches. See Figure 5.18.
12. Remove the nut, T-bolt and spacer that connect the
transmissions to each other. See Figure 5.19.
13. Remove the bolt holding the rear of the transmis-
sion to the torque bracket. See Figure 5.20.
Figure 5.18
Front transmission
bolt
Figure 5.19
Spacer
Nut
Figure 5.20
Torque bracket
