System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
PCI Express* and Legacy PCI Subsystem
Revision 1.1 Intel order number G90620-002 83
Byte Field Description
14 Event Data 1 [7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger
0h = Data Link Layer Protocol Error
1h = Surprise Link Down Error
2h = Completer Abort
3h = Unsupported Request
4h = Poisoned TLP
5h = Flow Control Protocol
6h = Completion Timeout
7h = Receiver Buffer Overflow
8h = ACS Violation
9h = Malformed TLP
Ah = ECRC Error
Bh = Received Fatal Message From Downstream
Ch = Unexpected Completion
Dh = Received ERR_NONFATAL Message
Eh = Uncorrectable Internal
Fh = MC Blocked TLP
15 Event Data 2 PCI Bus number
16 Event Data 3 [7:3] – PCI Device number
[2:0] – PCI Function number
The PCI Express* Fatal Error #2 is a continuation of the PCI Express* Fatal Error.
Table 68: PCI Express* Fatal Error #2 Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0033h = BIOS SMI Handler
11 Sensor Type 13h = Critical Interrupt
