System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 19
Sensor
Number
Sensor Name Details Section Next Steps
94h
Processor 1 Memory VRD Hot 0-1
(P1 Mem01 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
95h
Processor 1 Memory VRD Hot 2-3
(P1 Mem23 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
96h
Processor 2 Memory VRD Hot 0-1
(P2 Mem01 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
97h
Processor 2 Memory VRD Hot 2-3
(P2 Mem23 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
98h
Processor 3 Memory VRD Hot 0-1
(P3 Mem01 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
99h
Processor 3 Memory VRD Hot 2-3
(P4 Mem23 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
9Ah
Processor 4 Memory VRD Hot 0-1
(P4 Mem01 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
9Bh
Processor 4 Memory VRD Hot 2-3
(P4 Mem23 VRD Hot)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
A0h
Power Supply 1 Fan Tachometer 1
(PS1 Fan Tach 1)
Power Supply Fan Tachometer
Sensors
Power Supply Fan Tachometer Sensors – Next Steps
A1h
Power Supply 1 Fan Tachometer 2
(PS1 Fan Tach 2)
Power Supply Fan Tachometer
Sensors
Power Supply Fan Tachometer Sensors – Next Steps
A2h
Intel ® Xeon Phi
™
Coprocessor
Status 1
(MIC 1 Status)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Status Sensors
Intel ® Xeon Phi
™
Coprocessor (MIC) Status Sensors Next Steps
A3h
Intel ® Xeon Phi
™
Coprocessor
Status 2
(MIC 2 Status)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Status Sensors
Intel ® Xeon Phi
™
Coprocessor (MIC) Status Sensors Next Steps
A4h
Power Supply 2 Fan Tachometer 1
(PS2 Fan Tach 1)
Power Supply Fan Tachometer
Sensors
Power Supply Fan Tachometer Sensors – Next Steps
