System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 21
Sensor
Number
Sensor Name Details Section Next Steps
B7h
Processor 4 DIMM Aggregate
Thermal Margin 2
(P4 DIMM Thrm Mrgn2)
Thermal Margin Sensors Table 40: Thermal Margin Sensors – Next Steps
B8h
Node Auto-Shutdown Sensor
(Auto Shutdown)
Node Auto Shutdown Sensor Node Auto Shutdown Sensor – Next Steps
BAh-BFh
Fan Tachometer Sensors
(Chassis specific sensor names)
Fan Tachometer Sensors Table 30: Fan Tachometer Sensor – Event Trigger Offset – Next Steps
C0h-C3h
Processor 1 – 4 DIMM Thermal
Trip
(P1 – P4 Mem Thrm Trip)
DIMM Thermal Trip Sensors DIMM Thermal Trip Sensors – Next Steps
C4h
Intel ® Xeon Phi
™
Coprocessor
Thermal Margin 1
(MIC 1 Margin)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Thermal Margin Sensors
Not applicable
C5h
Intel ® Xeon Phi
™
Coprocessor
Thermal Margin 2
(MIC 2 Margin)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Thermal Margin Sensors
Not applicable
C6h
Intel ® Xeon Phi
™
Coprocessor
Thermal Margin 3
(MIC 3 Margin)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Thermal Margin Sensors
Not applicable
C7h
Intel ® Xeon Phi
™
Coprocessor
Thermal Margin 4
(MIC 4 Margin)
Intel ® Xeon Phi
™
Coprocessor
(MIC) Thermal Margin Sensors
Not applicable
C8h-CFh
Global Aggregate Temperature
Margin 1 -8
(Agg Therm Mrgn 1 – 8)
Thermal Margin Sensors Table 40: Thermal Margin Sensors – Next Steps
D0h
Baseboard +12V
(BB +12.0V)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
D1h
Baseboard +5V
(BB +5.0V)
Threshold-based Voltage
Sensors
Table 13: Threshold-based Voltage Sensors – Next Steps
