Sensor Cross Reference List
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
14 Intel order number G90620-002 Revision 1.1
Sensor
Number
Sensor Name Details Section Next Steps
0Ah
BMC Watchdog
(BMC Watchdog)
BMC Watchdog Sensor BMC Watchdog Sensor – Next Steps
0Bh
Voltage Regulator Watchdog
(VR Watchdog)
Voltage Regulator Watchdog
Timer Sensor
Voltage Regulator Watchdog Timer Sensor – Next Steps
0Ch
Fan Redundancy
(Fan Redundancy)
Fan Presence and Redundancy
Sensors
Table 34: Fan Redundancy Sensor – Event Trigger Offset – Next Steps
0Dh
SSB Thermal Trip
(SSB Thermal Trip)
Discrete Thermal Sensors Table 45: Discrete Thermal Sensors – Next Steps
0Eh
IO Module Presence
(IO Mod Presence)
Add-In Module Presence Sensor Add-In Module Presence – Next Steps
0Fh
SAS Module Presence
(SAS Mod Presence)
Add-In Module Presence Sensor Add-In Module Presence – Next Steps
10h
BMC Firmware Health
(BMC FW Health)
BMC FW Health Sensor BMC FW Health Sensor – Next Steps
11h
System Airflow
(System Airflow)
System Air Flow Monitoring
Sensor
Not applicable
12h
Firmware Update Status
(FW Update Status)
Firmware Update Status Sensor Not applicable
13h
IO Module2 Presence
(IO Mod2 Presence)
Add-In Module Presence Sensor Add-In Module Presence – Next Steps
14h
Baseboard Temperature 5
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
15h
Baseboard Temperature 6
(Platform Specific)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
16h
IO Module2 Temperature
(I/O Mod2 Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
17h
PCI Riser 3 Temperature
(PCI Riser 3 Temp)
Threshold-based Temperature
Sensors
Table 37: Temperature Sensors – Next Steps
