Processor Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
66 Intel order number G90620-002 Revision 1.1
Byte Field Description
2h = Link/PHY Init Failure with resultant degradation in link width
3h = PHY Layer detected drift buffer alarm
4h = PHY detected latency buffer rollover
5h = PHY Init Failure
6h = Link Layer generic control error (buffer overflow/underflow, credit underflow and so on)
7h = Parity error in link or PHY layer
8h = Protocol layer timeout detected
9h = Protocol layer failed response
Ah = Protocol layer illegal packet field, target Node ID Error, and so on
Bh = Protocol Layer Queue/table overflow/underflow
Ch = Viral Error
Dh = Protocol Layer parity error
Eh = Routing Table Error
Fh = (unused) = Reserved
15 Event Data 2 0-3 = CPU1-4
16 Event Data 3 Not used
The QPI Fatal Error #2 is a continuation of QPI Fatal Error.
Table 55: QPI Fatal #2 Error Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0033h = BIOS SMI Handler
11 Sensor Type 13h = Critical Interrupt
12 Sensor Number 17h
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 74h (OEM Discrete)
14 Event Data 1 [7:6] – 10b = OEM code in Event Data 2
