System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
Cooling Subsystem
Revision 1.1 Intel order number G90620-002 57
Sensor
Number
Sensor Name Event
Type
Event Trigger Offset Description Next Steps
Hex Description
97h P2 Mem23 VRD Hot Processor 2 Memory 2/3 voltage regulator
overheated
98h P3 Mem01 VRD Hot Processor 3 Memory 0/1 voltage regulator
overheated
99h P4 Mem23 VRD Hot Processor 3 Memory 2/3 voltage regulator
overheated
9Ah P4 Mem01 VRD Hot Processor 4 Memory 0/1 voltage regulator
overheated
9Bh P4 Mem23 VRD Hot Processor 4 Memory 2/3 voltage regulator
overheated
5.2.6 DIMM Thermal Trip Sensors
The BMC supports DIMM Thermal Trip monitoring that is instantiated as one aggregate IPMI discrete sensor per CPU. When a
DIMM Thermal Trip occurs, the system hardware will automatically power down the server and the BMC will assert the sensor offset
and log an event.
Table 46: DIMM Thermal Trip Typical Characteristics
Byte Field Description
11 Sensor Type 0Ch = Memory
12 Sensor Number C0h = Processor 1 DIMM Thermal Trip
C1h = Processor 2 DIMM Thermal Trip
C2h = Processor 3 DIMM Thermal Trip
C3h = Processor 4 DIMM Thermal Trip
13 Event Direction and
Event Type [7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1 [7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
