Cooling Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel ® Xeon ® Processor E5 4600/2600/2400/1600/1400 Product Families
48 Intel order number G90620-002 Revision 1.1
Byte Field Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 0Bh (Generic Discrete)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 34
15 Event Data 2 Not used
16 Event Data 3 Not used
The following table describes the severity of each of the event triggers for both assertion and deassertion.
Table 34: Fan Redundancy Sensor – Event Trigger Offset – Next Steps
Event Trigger Offset Description Next Steps
Hex Description
00h Fully redundant The system has lost one or more fans and is running in non-
redundant mode. There are enough fans to keep the system
properly cooled, but fan speeds will boost. Fan redundancy loss indicates failure of
one or more fans.
Look for lower (non-) critical fan errors,
or fan removal errors in the SEL, to
indicate which fan is causing the
problem, and follow the troubleshooting
steps for these event types.
01h Redundancy lost
02h Redundancy degraded
03h Non-redundant, sufficient from redundant
04h Non-redundant, sufficient from insufficient
05h Non-redundant, insufficient The system has lost fans and may no longer be able to cool
itself adequately. Overheating may occur if this situation
remains for a longer period of time.
06h Non-redundant, degraded from fully
redundant The system has lost one or more fans and is running in non-
redundant mode. There are enough fans to keep the system
properly cooled, but fan speeds will boost.
07h Redundant, degraded from non-redundant The system has lost one or more fans and is running in a
degraded mode, but still is redundant. There are enough fans
to keep the system properly cooled.
